SLIM-BASIC COMFORT AIR KIT
Chapter 3
USE AND MAINTENANCE MANUAL
page
6
Basic comfort air kit
Technical dept. - All rights reserved by MCZ Group S.p.A. - Reproduction prohibited
2. SLIM FORCED VENTILATION KIT
2.1.1. Comfort Air Kit Components Slim Wood – Single package
1. Fan kit w/out box (2 pieces)
2. Pipe Diam.60 L=1.5 m (2 pieces)
3. Flexible hose Diam.10 L=1.5 m (2 pieces)
4. Flange Ø 100 (2 pieces)
5. Pipe clamp Diam.60-170 (4 pieces)
6. Pipe clamp Diam.64-76 (4 pieces)
7. Control unit+connection diagram
8. Remote control
9. Sensor
+ Wiring/Screws/Manual
N.B. control unit + remote control same package
2.1.2. Comfort Air Kit Components Slim Gas – single package
1.
Fan kit w/out box (1 piece)
2.
Flex hose Diam.6 L=1.5 m (1 piece)
3.
Flexible hose Diam.10 L=1.5 m (1 piece)
4.
Control unit+connection diagram
5.
Remote control
6.
Flange Ø 100 (1 piece)
7.
Pipe clamp Diam.60-170 (4 pieces)
N.B. control unit + remote control same
package
1
2
3
8
6
5
4
7
1
2
3
7
6
5
4
9
