Pressure Systems, Inc. NetScanner™ System (9016, 9021, & 9022) User’s Manual
www.PressureSystems.com 3 - 63
NOTE: Coefficients used for typical applications are shown in BOLD type.
All other coefficients are typically not used outside of advanced
diagnostic functions.
The coefficients of internal DH200 transducers used in the Model 9016 are selected
with array indexes aa=01 through 10 (hex). Coefficients of external 9400
transducers used by Models 9021 and 9022 (digitally compensated) are selected
with array indexes aa=01 through 0C (hex). All valid coefficient indexes (for each
of these arrays) are listed in the following table:
cc Transducer Coefficient Description Datum
Type
00 Re-zero Cal Adjustment (offset) term FLOAT
01 Span Cal Adjustment (gain) term FLOAT
02 Dynamic EU Conversion coefficient c0 FLOAT
03 Dynamic EU Conversion coefficient c1 FLOAT
04 Dynamic EU Conversion coefficient c2 FLOAT
05 Dynamic EU Conversion coefficient c3 FLOAT
06 Reserved for Factory Use ----
07 User Defined Date field (see end-of-table note) INTEGER
08 Date of Factory Calibration (see end-of-table note) INTEGER
09 Transducer Manufacturing Reference number INTEGER
0A Transducer Full-Scale Range code (see Appendix F) INTEGER
0B-0F Temperature 1, Pressures 1-5 voltages FLOAT
10-14 Temperature 2, Pressures 1-5 voltages FLOAT
15-19 Temperature 3, Pressures 1-5 voltages FLOAT
1A-1E Temperature 4, Pressures 1-5 voltages FLOAT
1F-23 Temperature 5, Pressures 1-5 voltages FLOAT
