Pressure Systems, Inc. NetScanner™ System (9016, 9021, & 9022) User’s Manual
www.PressureSystems.com 5 - 3
Table 5.1 provides a convenient cross reference summary of the components found in each
Intelligent Pressure Scanner. This may be used as a guide to identify the appropriate component
replacement sections in this chapter.
Table 5.1
Component Cross Reference
Component Section 9016 9021 9022
PC -280 M icrop roce ssor P CB Assem bly 5.1.3 .3 T T T
PC -206 Amplifier/M UX PC B A ssemb ly 5.1.3 .1 T
PC -242 Amplifier/M UX PC B A ssemb ly 5.1.3 .2 T
Interna l Pne uma tic Calib ration M anifold 5.1.6 T
Internal Solenoid Valves 5.1.5 T
Internal DH-200 Transducer 5.1.4 T
PC-315 Connector Interface PCB 5.1.3 .4 T
PC-316 or PC 33 9 Signal Conditioning
PCB 5.1.3 .4 T
PC-317 MUX PCB 5.1.3 .4 T
5.1.1 Common Maintenance
The NetScanner ™ System Intelligent Pressure Scanners are designed for rugged use. No special
preventive maintenance is required, although periodic maintenance may be required to replace worn
or damaged components. Upgrades or modifications of module hardware or firmware may also be
periodically required. For users who wish to do their own maintenance and repairs, maintenance kits
and replacement parts for each model may be purchased from the factory.
