A detailed step-by-step procedure follows that includes the specific 9021/9022 commands to be sent
to the module under test.
DESCRIPTION
9021/9022 COMMAND
Set AD averaging to 32 to minimize reading jitter
w1020
Turn off front-end calibration function (9022 ONLY)
w2200 00
Set all channels to gain of 1 (or 20, 45, 90)
1
w1500
(or w 150 1, w 150 2, or w1503 for gain of 20,45, or 90)
Read current G=1 reference coefficient from
9021/9022 in ASCII floating point format
2
u01104
(u01 18 fo r 90 22 te mpe rature r eferen ce co efficient)
Ap ply 4.5 00 V DC to 90 21/9 022 chann el 1
**
Read mea sured voltage from channel 1 in ASCII
floating point (data format 0)
r00010
(t00010 for temperature voltage)
Calculate difference between actual applied voltage
and 9021 /9022 reported vo ltage
**
Download new reference coefficient for G=1 in ASCII
floating point format
3
v0110 4 x.xxxx (x.xxxx is new coefficient)
(v01118 x.xxxx for 9022 temperature reference
coe fficient)
Store coefficient to 9021/902 2 FLAS H mem ory
w07
Reboot module to force new coefficients to take effect
**
1
The gain control commands for the 9021/9022 are summarized in the following table:
Gain
9021/9022
Command
1
w1500
20
w1501
45
w1502
90
w1503
2
Commands to read the respective gain coefficient commands are summarized in the following
table.
