Pressure Systems, Inc. NetScanner™ System (9016, 9021, & 9022) User’s Manual
www.PressureSystems.com C - 1
Appendix C
Cable Diagrams
Description Applicable Models Page
Ethernet Interface Cable - unterminated host
Ethernet Interface Cable 9016, 9021, and 9022
9016, 9021, and 9022 C-2
C-
3
9400 Series/9021 (D-Shell) Cable 9021 C-4
9400 Series/9022 (Circular Connector)
Cable 9022 C-5
9021 to Series 27 Interface Cable 9021 C-6
9022 to Series 27 Interface Cable 9022 C-7
Calibration Cable 9022 C-8
3 rd Party Sensor Interface Cable 9022 C-9
