Page 2
DO NOT operate the staple gun
when you are tired or under the influence of alcohol, drugs or intoxicating medication.
DO NOT leave a hot staple gun unattended. ( If you are leaving the work area even for a short period of time switch it off and allow to
cool.)
DO NOT use the staple gun for any purpose other than that for which it has been designed.
DO NOT allow untrained persons to operate the staple gun.
DO NOT touch the workpiece as it will be very hot. Allow to cool.
DO NOT operate the staple gun if damaged.
fig.1
2. INTRODUCTION
3. SPECIFICATION
4. OPERATION
Pistol grip design improves control and accuracy when carrying out repairs. Features high, medium and low power option. Ideal for workbench,
where frequent use is required. Supplied with staples; 100 x 0.6mm U-shaped, 100 x 0.8mm U-shaped, 100 x 0.6mm V-shaped.
Model No: . . . . . . . . . . . . . . . . . . . . . . . . . . . . .RE023
Replacement Staples: . . . . . . . . . . . . . . . . . . . .(Packs of 100) RE06 (0.6mm), RE06V (0.6mm), RE08(0.8mm)
4.1.
Plug the stapler in and switch the gun on using the rocker switch underneath.
4.2.
Choose a suitable heating repair pin and place it into the tip of the stapler.
4.3.
Set the power using the button on the side, see fig.1, green light = low, amber light = medium, red light = high.
4.4.
Keep the stapler perpendicular to the damaged surface, press the control switch and after a few seconds touch onto the plastic.
4.5.
When the pin is half way into the plastic material, stop pressing and release the power trigger. Wait for a few seconds until the repair
part becomes firm.
4.6. Pull back the handle to release the pin from the device.
4.7.
If the damage is excessively long and/or wide insert extra pins, 1/2 “ apart.
4.8.
Cut off the pins with a side cutter, then grind the remaining part with a grinder or sander.
NOTE: DO NOT press the pins too hard, they may penetrate the plastic too far.
NOTE: Rest the stapler for 5 to 10 minutes after 40 cycles of continuous use, in order to extend the product’s life.
Ensure the workpiece is adequately held before operating the staple gun.
Always lay the staple gun on its side so that the tip cannot make contact with the work surface.
Always use staple gun in a well vetilated atmosphere or alternatively wear respiratory protection.
Ensure that when the staple gun is put down during use that the tip is not near to or in contact with any material that may burn or melt
including the product’s own supply lead.
After use always keep the staple gun in its original package in a safe place away from children.
DO NOT touch the staple during its warm up phase.
DO NOT use in wet or damp conditions.
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
IMPORTANT: no liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which will be required for any claim.
INFORMATION: For a copy of our latest catalogue and promotions call us on 01284 757525 and leave your full name and address, including postcode.
01284 757500
01284 703534
Sole UK Distributor, Sealey Group,
Kempson Way, Suffolk Business Park
,
Bury St. Edmunds, Suffolk,
IP32 7AR
www.sealey.co.uk
Environmental Protection
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment.
WEEE Regulations
Dispose of this product at the end of its working life in compliance with the EU Directive on
Waste Electrical and Electronic Equipment (WEEE). When the product is no longer required, it must be disposed
of in an environmentally protective way. Contact your local solid waste authority for recycling information.
Parts support is available for this product. To obtain a parts listing and/or diagram,
please log on to www.sealey.co.uk, email [email protected] or telephone 01284 757500.
Original Language Version
© Jack Sealey Limited
RE023 Issue: 1 - 15/05/14
