2. INTRODUCTION & SPECIFICATIONS
3.1. Air Supply
3.1.1. Ensure the sander air valve (or throttle) is in the "off" position before connecting to the air supply.
3.1.2. You will require an air pressure between 70-90psi, and an air flow according to the specification above.
3.1.3.  WARNING! Ensure the air supply is clean and does not exceed 90psi while operating the sander.
too high an air pressure and unclean air will shorten the product life due to excessive wear, and may be
dangerous causing damage and/or personal injury.
3.1.4. Drain the air tank daily. Water in the air line will damage the sander and will invalidate your warranty.
3.1.5. Clean air inlet filter weekly. Recommended hook-up procedure is shown in fig 1.
3.1.6. Line pressure should be increased to compensate for unusually long air hoses (over 8 metres).
the minimum hose diameter should be 1/4” I.D. and fittings must have the same inside dimensions.
3.1.7. Keep hose away from heat, oil and sharp edges. Check hoses for wear, and make certain that all
connections are secure.
3.2. Couplings.
Vibration may cause failure if a quick change coupling is connected directly to the air sander. to overcome this,
connect a leader hose to the sander. A quick change coupling may then be used to connect the leader hose to
the air line recoil hose. See figs 1 & 2.
3. PREPARING SANDER FOR USE
1.2. LEAD PAINT WARNING!
Paint once contained lead as a traditional ingredient. Contact with the dust from the removal of such
paint is toxic and must therefore be avoided. the following action must be taken before using the
sander on a surface that you suspect may contain lead paint.
1. User must determine potential hazard relating to age of paint to be removed.
(Modern paints do not have lead content).
2. DANGER! Keep all persons and pets away from the working area. the following persons are
particularly vulnerable to the effects of lead paint dust: Expectant women, babies and children.
3. We recommend personal protection by using the following safety items:
a) Paint Spray Respirator (Our ref SSP1699)
b) PE Coated Hooded Coverall (Our ref SSP266). c) Latex Gloves (Our ref SSP24).
4. take adequate measures to contain the paint dust, flakes and scrapings.
5. Continue to wear safety equipment as in (3) above and thoroughly clean all areas when task is
complete. Ensure paint waste is disposed of in sealed bags or containers according to local
regulations.
Durable, lightweight body with moulded handle, reducing chill effects and providing extra control.
Fitted with dual exhaust ports and air control valve. Supplied with Ø150mm hook-and-loop pad.
Ideal for the DIY enthusiast and light garage use.
Model No:. . . . . . . . . . . . . . . . . . . . . . . . . . S01044
thread Size: . . . . . . . . . . . . . . . . . . . . . . 5/16” UNF
Free Speed: . . . . . . . . . . . . . . . . . . . . . . . 1000rpm
Orbit Size: . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5mm
Air consumption: . . . . . . . . . . . . . . . . . . . . . . . 4cfm
Operating Pressure: . . . . . . . . . . . . . . . . . . . . 90psi
Air Inlet Size:. . . . . . . . . . . . . . . . . . . . . . . . ¼” BSP
Weight: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.73kg
Noise Power: . . . . . . . . . . . . . . . . . . . . . . . . 94dBA
Noise Pressure:. . . . . . . . . . . . . . . . . . . . . . . 83dBA
Vibration: . . . . . . . . . . . . . . . . . . . . . . . . . . . 4.6m/s²
Uncertainty Value (k): . . . . . . . . . . . . . . . . 1.84m/s²
S01044 Issue: 2(SP)- 14/08/13 Original Language Version © Jack Sealey Limited
