The 16AI, 8IO, and MultiFlex Inputs
Input and Output Setup
•
9
-
5
207-1000 Refrigerant
Level Trans-
ducer (Hansen
Probe)
Down
1.
Wire BLACK ground
wire from “GND”
sensor terminal to odd
numbered board ter-
minal.
2.
Wire GREEN signal
wire from “SIGNAL”
sensor terminal to
even numbered board
terminal.
3.
Wire RED power wire
from “POWER” sen-
sor terminal to
+12VDC terminal on
board.
203-1902 Dewpoint
Probe
Up
1.
Connect the WHITE
and GREEN wires to
AC1 and AC2 power
terminals.
2.
Connect BLACK
ground wire to odd
numbered board termi-
nal.
3.
Connect RED signal
wire to even numbered
board terminal.
P/N
Sensor
Input Type
Dip Switch
Wiring
Table 9-1
- Sensor Wiring
