Appendix 177
Supported Media
The following media can be used with the printer. Print quality is greatly affected by the
type and quality of media used. Choose a media suited to the task at hand. For information
on use, refer to the documentation supplied with the media or contact the manufacturer.
We recommend that you print a test run and check the results before purchasing media in
large quantities.
*Minimum media width for ink layering is 508 mm (20 in.)
Waste Ink Bottle T724000 Identical to the waste ink bottle supplied with the printer.
Media Holding Plate C12C890891 Identical to the media holding plate supplied with the printer.
High Speed Dryer C890751 Uses a fan to blow air over the media and assist drying (included with
the S50670). See “The Media Setup Menu” on page 152.
Heavy Roll Media System C12C890761 A media feeding unit and auto take-up reel for heavy rolls (up to 80 kg
or 176.4 lb).
Important:
Do not use media that is wrinkled, scuffed, torn, or dirty.
Note:
Ink layering is not available with some media types, such as banner and canvas.
Standard Roll Media System
Roll core size 2 or 3 inch
Roll outer
diameter Up to 250 mm (9.8 inches)
Media width 300* to 1626 mm (11.8 to 64 inches)
Media thickness Up to 1 mm (0.04 inch)
Roll weight Up to 40 kg (88.2 lb)
Heavy Roll Media System
Roll core size 2 or 3 inch
Roll outer
diameter Up to 300 mm (11.8 inches)
Media width 300 to 1626 mm (11.8 to 64 inches)
Media thickness Up to 1 mm (0.04 inch)
Roll weight Up to 80 kg (176.4 lb)
Product Part number Explanation
