Epson STYLUS NX100/NX105/SX100/SX105/TX100/TX101/TX102/TX103/TX105/TX106/TX109/ME 300
Revision A
ADJUSTMENT
Adjustment Items and Overview
102
Confidential
Table 5-2. Maintenance Items
Maintenance Item
Purpose
Method Outline
Tool
Waste ink pad
counter
The printer indicates a maintenance error when the waste ink pad counter
reaches its maximum. Use this to reset the counter after replacing the Waste
Ink Pad. If you find the counter is close to the maximum level during
servicing, carry out the pad replacement and the counter reset to avoid the
printer’s immediate return from the user due to the maintenance error.
After replacing the Waste Ink Pad, reset the counter to its default.
• Adjustment Program
Ink charge
This must be carried out after replacing the Printhead in order to fill ink
inside the new Printhead. The Printhead becomes ready for print.
Filling ink inside the Printhead is automatically performed. Print a
nozzle check pattern to check if all nozzles fire ink properly.
• Adjustment Program
Table 5-3. Additional Functions
Additional Functions
Purpose
Method Outline
Tool
Final check pattern
A4 size
Use this to check if all the adjustments have been
properly made.
all the adjustment patterns are printed automatically.
• Adjustment Program
US Letter size
EEPROM dump
Use this to readout the EEPROM data for analysis. all the EEPROM data is automatically readout and stored as a file.
• Adjustment Program
Printer information
check
Manual CL counter
Use this to readout information on the printer
operations.
The printer information is automatically readout.
• Adjustment Program
I/C exchange CL counter
Timer CL counter
Print path counter
