Chassis Environmental Statistics Configuration Screen
11-14
Module Statistics Menu Screens
11.5 CHASSIS ENVIRONMENTAL STATISTICS
CONFIGURATION SCREEN
When to Use
To obtain Chassis statistics for fan and power supplies.
How to Access
Use the arrow keys to highlight the Chassis Environmental Statistics Configuration screen on
the Module Statistics menu screen and press ENTER. The Chassis Environmental Statistics
Configuration screen
displays.
Screen Example
Figure 11-5
Chassis Environmental Statistics Configuration Screen
3528-01_02
RETURN
EXIT
Chassis Power Redundancy:
Not Available
Power Supply #1 Status:
Fault
Power Supply #2 Status:
Normal
Chassis Fans Status:
Normal
