Transmit Queues Configuration Screen
802.1p Configuration Menu Screens 9-13
How to Access
Use the arrow keys to highlight the TRANSMIT QUEUES CONFIGURATION menu item on
the 802.1p Configuration Menu screen and press ENTER. The Transmit Queues Configuration
screen,
Figure 9-5 , displays.
Screen Example
Figure 9-5 Transmit Queues Configuration Screen
[WEIGHTED]
Q0 Q1 Q2 Q3
[0%] + [25%] + [38%] + [31%] = 94%
Must add up to 100% !
2504-96w
Current Queueing Mode:
Weights:
These fields display only when the Current Queueing Mode is set to WEIGHTED.
The "Must add up to 100%!" message displays as long as the total percentage is not
100%, as shown.
RETURN SAVE SET ALL PORTS
RETURN
Port: [1] Number of Queues: 4
EXIT
Ethernet Frontpanel
