background image

31

© 2010 Magnum Energy, Inc.

Troubleshooting

7.0 Troubleshooting

Info: Before using this table to troubleshoot, review Table 6-1,

LED Indicator Guide.

Use the table below and the Status display on your remote/router to deter-

mine the problem.

ME-RC50 - METER pushbutton, 04 BM: Status display
ME-ARC50 - METER pushbutton, 04A BMK Status display
ME-RTR - METER pushbutton, 04A BMK SOC display



Symptom

Solution

1. Battery meter

displays not

responsive and giving

incorrect readings; or,

2. BM Status = “No

Comm” or “Pwr-up

Fault”

Ensure LED on Sense Module is solid green

(indicates normal operation). If not green, use

Table 6-1, LED Indicator to troubleshoot.

If the LED is green, disconnect the terminal

block for 5 seconds and then reconnect to reset

the Sense Module.

AH I/O reading resets

This is normal. After a full battery has

discharged ≥ 0.5% of the its capacity, the AH

I/O synchronizes and the value resets.

DC Volts reading is

incorrect

Measure the voltage between the red (terminal

4/positive) and black (terminal 3/negative) wire

on the terminal block in the Sense Module. If

the voltage at the Sense Module and the voltage

displayed on the remote’s/router’s display differ

by more than 0.2 volts, then examine these

wires for an open circuit or a bad connection.

Reconnect or replace if necessary. Voltage from

terminal 3 to 4 must be from 7 to 70 volts DC.

DC Amps reading is

incorrect

Examine the twisted-pair wires (orange and

blue) for an open circuit or bad connections.

Reconnect or replace if necessary. Ensure the

wires are fully twisted up to the Sense Module

and to the DC shunt.

DC Amps polarity

reading is reversed

(i.e., positive while

inverting and/or

negative while battery

charging)

The leads from the twisted-pair (orange and

blue) to the shunt sense screws are reversed.

Reverse the leads of the twisted-pair wire on

the shunt or at the terminal block. See Figure

2-3 for the correct wiring sequence.

The Min DC or Max

DC displays show 0.0

volts

The battery monitor is not communicating.

Check that the connections to the Sense Module

are correct.

Table 7-1, Troubleshooting Guide
