10 CC-Link Code Numbers
YASKAWA ELECTRIC
SIEP C730600 44A YASKAWA AC Drive-Option Card CC-Link Technical Manual
33
1021H
Minor fault contents 3
0
Reserved
–
1
Motor Overheat (oH3)
0022H
2
Reserved
–
3
Reserved
–
4
Reserved
–
5
Reserved
–
6
PID Feedback Loss (FbL)
0027H
7
Excessive PID Feedback (FbH)
0028H
8
Reserved
–
9
Drive Disabled (dnE)
002AH
A
PG Hardware Fault (PGoH)
002BH
B
Reserved
–
C
Reserved
–
D
Reserved
–
E
Reserved
–
F
Reserved
–
1022H
Minor fault contents 4
–
0
Reserved
1
Station Number Setting Error (AEr)
0032H
2
Reserved
–
3
Current Alarm (HCA)
0034H
4
Cooling Fan Maintenance Time (LT-1)
0035H
5
Capacitor Maintenance Time (LT-2)
0036H
6
Reserved
–
7
Reserved
–
8
External Fault (input terminal S1) (EF1)
0039H
9
External Fault (input terminal S2) (EF2)
003AH
A
Safe Disable Signal Input (HbbF)
003BH
B
Safe Disable Signal Input (Hbb)
003CH
C
Mechanical Weakening Detection 1 (oL5)
003DH
D
Mechanical Weakening Detection 2 (UL5)
003EH
E
Reserved
–
F
Reserved
–
1023H
Minor fault contents 5
–
0
Output Voltage Detection Fault (voF)
0041H
1
IGBT Maintenance Time (90%) (TrPC)
0042H
2
Soft Charge Bypass Relay Maintenance Time (LT-3)
0043H
3
IGBT Maintenance Time (50%) (LT-4)
0044H
4
Braking Transistor Overload Fault (boL)
0045H
5
Reserved
–
6
Reserved
–
7
Reserved
–
8
DriveWorksEZ Alarm (dWAL)
0049H
9
Reserved
–
A
Reserved
–
B
Reserved
–
C
Reserved
–
D
Reserved
–
E
Reserved
–
F
Reserved
–
Monitor Code
Minor Fault Name
Minor Fault Code
(MEMOBUS Register 07FH)
BIT
