Everpure QC7I Single-MH2 - Manual (Page 26)

Customer Service / Technical Support: 800.942.1153 / 630.307.3000 n Fax: 800.942.0081 / 920.803.3805 24
COMBINATION FILTRATION SYSTEMS
Up to 7.5 GPM Up to 10.0 GPM
High Flow CSR Triple 7FC High Flow CSR Quad 7FC
Note: Systems also available with low pressure alarm, indicating when filter has become plugged.
Replacement Cartridges
Use only genuine Everpure ® replacement cartridges to protect
your system’s superior performance, NSF certification, and warranty.
High Flow CSR FC Systems
High Flow CSR FC Systems are "right-sized" for combination applications for higher flow rates.
System
Part
Number
Flow Rate Rated Capacity Dimensions (H x W x D) Ship Wt.
List Price in cm lbs kgs gpm lpm gallons litres
High Flow CSR Triple 7FC EV9329-73 7.5 28.39 75,000 283,905 25.6 x 30 x 6.75 65.0 x 76.2 x 17.1 43 19.4 $1,748.00
High Flow CSR Quad 4FC* EV9329-44 10.0 37.85 60,000 227,125 19.5 x 34 x 6.75 49.53 x 86.4 x 17.1 37 16.8 1,749.00
High Flow CSR Quad 7FC EV9329-74 10.0 37.85 100,000 378,541 25.6 x 34 x 6.75 65.0 x 86.4 x 17.1 48 21.8 2,130.00
*High Flow CSR Quad 4FC not Shown. Uses EC110 Prefilter.
Product
Part
Number
Capacity Micron
Rating NSF Std 42 Chlorine Reduction T&O Reduction Particulate Reduction Bacteriostatic (NSF-Certified) NSF Std 53 Cyst Reduction Chloramine Reduction
Pack
Size
Ship Wt. List
Price
Flow Rate
gallons litres lb kg gpm lpm
4FC EV9692-21 2.5 9.46 15,000 56,781 0.5 • • • • • • • 1 2 .91 $130.00
7FC EV9692-61 2.5 9.46 25,000 94,635 0.5 • • • • • • • 1 3 1.36 208.00
4FC5 EV9693-21 2.5 9.46 15,000 56,781 5.0 • • • • • 1 2 .91 124.00
7FC5 EV9693-61 2.5 9.46 25,000 94,635 5.0 • • • • • 1 3 1.36 198.00
EC110* EV9534-12 –– –– –– –– 10 • 12 5 2.3 6.80
EC210** EV9534-26 –– –– –– –– 10 • 6 5 2.3 12.70
SS-IMF EV9799-32 –– –– –– –– –– 12 4 1.8 75.30
SS-XL ScaleStick ® EV9799-42 –– –– –– –– –– 6 12 2.7 295.00
4FC5 7FC5 4FC 7FC EC110 EC210
*EC110 Prefilter used in systems with 10" prefilter bowl.
**EC210 Prefilter used in systems with 20" prefilter bowl.
SS-IMF SS-XL
