SMA Solar Technology AG Commissioning
User Manual BeamBT-BEN094911 31
Enter the new system password in the Sunny Beam
41. Move the selection frame to "System password" by turning the button.
☑ The field "System password" becomes dark.
42. Press the button.
☑ The input page appears.
43. Choose the button with the arrow and press the button
again to delete the set system password.
44. In order to enter the new system password, turn the button until the desired character is
highlighted. Then press the button in order to select the character. Enter the new system
password for users.
45. Select the check mark to save the entered system password.
☑ The list of connected inverters is displayed.
46. Select "OK".
☑ The first chart for the complete PV system, "Power today", is displayed. The Sunny Beam is now
in operation.
Arrow: deletes the character which was entered last.
Cross: cancels the input action.
Checkmark: saves the system password for the Sunny
Beam.
