SMA Solar Technology AG 8 Replacing the Fuse Link
Operating Manual BatFuse-BE-en-30 19
8 Replacing the Fuse Link
1. Remove the enclosure lid of the BatFuse.
2. Open the load-break switch.
3. Push the interlock on the fuse holder down and slide
the defective fuse link out of the fuse holder.
4. Put a new fuse link into the holder and slide it in.
☑ The fuse link snaps audibly into place.
5. Ensure that the correct fuse link is plugged into the
fuse holder (see Section 4.1 "BatFuse", page 9).
6. Close the load-break switch quickly.
7. Close the enclosure lid of the BatFuse.
