ShoreLand'r SLKB150TA User Manual
Page 5
Midwest Industries, Inc.
Ida Grove, IA 51445
800.859.3028
www.shorelandr.com
0003957
Page 5
04/10/2008
Battery Box
SD Control Module
Actuator
Brakeline Port
Diagram B
Jack:
Remove the hardware bag provided by the jack manufacturer and
take out the mounting plates. From hardware bag (66270), take out
four (4) 3/8” X 6” stainless steel hex bolts and four (4) 3/8” stainless
steel lock nuts with nylon inserts, Position the jack on the tongue
in a location that best fits your watercraft. Secure with the stainless
steel hardware. The remaining hardware bag that was removed
from the jack may be discarded.
