Design Spot 575E™
©Elation Professional® 54
Design Spot 575E™
24 (16bit – default) or 22 (8bit – user selectable)
Drive
Standard DMX-512, 3 pole XLR; [+] = Pin 3 [-] = Pin 2 [Ground] = Pin 1 or 5 pole XLR; n/a = Pin
5, n/a = Pin 4, [+] = Pin 3, [-] = Pin 2, [Ground] = Pin 1
Starting DMX [001].
Pan / Tilt
Pan - movement
630° in max. 2.0 seconds, 16 bit resolution
Tilt - movement
265° in max. 1.5 seconds, 16 bit resolution
Weights and measures
Width of the base
61cm (W) x 46cm (L) x 51cm (H) ~ Head vertical
Length of the base
32.5Kgs / 72Lbs
Height (head vertical)
Weight (net)
32.5Kgs / 72Lbs
Please Note: Specifications and improvements in the design of this unit and this manual are subject to change without any prior written notice.
