Elation Professional 575E - Manual (Page 24)

Design Spot 575E™
©Elation Professional® 24
Design Spot 575E™
Program 10 01=SCxxx
Step
64=SCxxx
Program in loop
Save and exit
Edit Scenes Edit Scene 001
~ Edit Scene
250
Pan, Tilt…
--Scenes
Time--
Input By
Outside
Pan=xxx…
TIME=xx.xs
Save and automatically
return
Scene edit mode
Rec. Controller XX~XX Automatic scene record
1. DMX address setting
After applying power and the rest process the Design Spot 575™ LCD will display the
fixture’s current DMX. If the fixture is not receiving a DMX signal the display will flash
continuously. To set or adjust a DMX address, please follow the procedure below:
1. Toggle through the menu by pressing the Up and Down buttons until the display
shows “Set DMX Address.” Tap the enter button to make changes to the address,.
2. While the current three-digit address is flashing, use the Up and Down buttons to
select adjust the address. Lock your new address into the unit’s memory by
pressing the Enter button.
The DMX address is non-destructible and will remain in the fixture’s memory even
when power to the fixture has been switched off. Memory is backed-up and retained by
an internal power source with a five year shelf life.
2. Display the DMX 512 value of each channel
With this function you can display the DMX 512 value of each channel. The display will
automatically readout the changing DMX values as they are received.
3. Slave setting
With this function, you can define the device as slave for operation in Master/Slave
mode.
