Design Spot 575E™
©Elation Professional® 36
Design Spot 575E™
Channel 1 - Pan movement 8bit:
Channel 2 - Pan fine 16bit
Channel 3 - Tilt movement 8bit:
Channel 4 - Tilt fine 16bit
Channel 5 - Color Wheel:
0-13 Open / white
14-27 Red
28-41 Blue
42-55 Green
56-69 Yellow
70-83 Magenta
84-97 Orange
98-111 UV Filter
112-127 Pink
128-187 Forwards rainbow effect from fast to slow
188-193 No rotation
194-255 Backwards rainbow effect from slow to fast
Channel 6 - Cyan Color Wheel:
0-255 Cyan (0-white, 255-100% Cyan)
Channel 7 - Magenta Color Wheel:
0-255 Magenta (0-white, 255-100% magenta)
Channel 8 - Yellow Color Wheel:
0-255 Yellow (0-white, 255-100% Yellow)
Channel 9 – Gobo Wheel 1 - rotating gobos:
0-9 Open
10-19 Gobo 1
20-29 Gobo 2
30-39 Gobo 3
40-49 Gobo 4
50-59 Gobo 5
60-69 Gobo 6
70-89 Gobo 1 shake slow to fast
90-109 Gobo 2 shake slow to fast
