v4.0
DCR 4000 User’s Guide | Menu Structure 3-1
Chapter 3
Menu Structure
From the Idle screen, further menus are available
All menu navigation is carried out by means of the four buttons: [UP], [DOWN], [ESC] and [SEL]
(select). The cursor is a right pointing '>' at the left hand side of the screen. At the right of the
screen a down arrow or up arrow shows whether there are more options which can be
reached by means of the [UP] and [DOWN] buttons.
Pressing [SEL] opens the selected menu item and moves to the next level down in the
structure, while pressing [ESC] returns to the previous level.
In the Idle screen shown above, the cursor is pointing at the currently selected TAKE. Pressing
[DOWN] once moves the cursor to the Metadata selection, and pressing [DOWN] again
causes the screen to scroll to show the next line, as shown here
There are three lines available on the top menu level:
– TAKE
– METADATA
– TOOLS AND SETTINGS
RECORD RECORD
POWER POWER
LIGHT LIGHT
ESC ESC UP UP
DOWN DOWN
PLAY PLAY
READY READY
SEL SEL
PLAY PLAY STOP STOP REC REC
REMAINING TIME 02:12
IN:1080psf24 dL ...
> TAKE 009 03:28
NO METADATA ↓
RECORD RECORD
POWER POWER
LIGHT LIGHT
ESC ESC UP UP
DOWN DOWN
PLAY PLAY
READY READY
SEL SEL
PLAY PLAY STOP STOP REC REC
REMAINING TIME 35%
TAKE 009 03:28 ↑
NO METADATA
> TOOLS AND SETTINGS
