Grass Valley DHP v.1.1 - Manual (Page 57)

49
Misc. Topics
Chapter 4 provides additional information.
Topics
Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Slot Numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Parts
I/O Cards
Order Code Description
8144-3GIG-IN-COAX
Standard 9-input card, 3Gig, HD, or SD, for use with coax connectors for
the NV8144.
8144-3GIG-OUT-COAX
Standard 18-output card, 3Gig, HD, or SD, for use with coax connectors
for the NV8144.
8144-HD-IN-COAX
Standard 9-input card, HD or SD, for use with coax connectors for the
NV8144.
8144-HD-OUT-COAX
Standard 18-output card, HD or SD, for use with coax connectors for the
NV8144.
8500-3GIG-IN-COAX
Standard 9-input card, 3Gig, HD, or SD, for use with coax connectors.
8500-3GIG-IN-FIBER
Standard 9-input card, 3Gig, HD, or SD, for use with SFP connectors.
8500-3GIG-OUT-COAX
Standard 18-output card, 3Gig, HD, or SD, for use with coax connectors.
8500-3GIG-OUT-COAX-EXP
Standard 8-output expansion card, 3Gig, HD, or SD, for use with coax
connectors.
8500-3GIG-OUT-FIBER
Standard 18-output card, 3Gig, HD, or SD, for use with SFP connectors.
8500-3GIG-OUT-FIBER-EXP
Standard 8-output expansion card, 3Gig, HD, or SD, for use with SFP con-
nectors.
8500-AES-ASYNC-IN
Standard 9-input card, AES async, for use with coax connectors.
8500-AES-ASYNC-OUT
Standard 18-output card, AES async, for use with coax connectors.
8500-AES-ASYNC-OUT-EXP
Standard 8-output expansion card, AES async, for use with coax connec-
tors.
8500-HD-IN-COAX
Standard 9-input card, HD or SD, for use with coax connectors.
8500-HD-OUT-COAX
Standard 18-input card (HD or SD) for use with coax connectors.
8500-HD-OUT-COAX-EXP
Standard 9-output expansion card (HD or SD) for use with coax connec-
tors.
