Installation
Installation
To install the Kameleon modules, perform the following steps:
1. Place the KAM-AES-R passive rear module in a rear frame slot and
tighten the screws on each side of the rear module.
2. Cable the signal ports.
All Kameleon modules can be inserted and removed from a 2000 Series
Kameleon Frame with power on.
Note Remove the front processing module before removing the rear I/O module.
System Requirements
For proper operation of the KAM-DEC-2AES modules, the frame must be
a 2000T1DNG or 2000T3NG which include the following components:
• 2000NET module (software version 3.2.2 or later recommended for full
functionality)
• 2000GEN module
• Dual 130W power supplies in the 2000T1DNG frame
• Single 240W power supply and 2000FAN in the 2000T3NG frame
Frame Capacity
The 1 RU 2000T1DNG (with dual 130W power supplies, 2000NET and
2000GEN modules) frames have no Kameleon module capacity limitations.
The 3 RU 2000T3NG (single 240W p/s, 2000FAN, 2000NET and 2000GEN
modules) frame can be fully populated with Kameleon modules when the
2000FAN fan sled and two power sleds are installed.
Table 1 provides the maximum Kameleon module count for frame types.
Table 1. Power, Cooling, and Module Capacity of 2000 Series Kameleon Frames
Item
2000T3NG
Kameleon Frame
Capacity
2000T1DNG
Kameleon Frame
Capacity
KAM-DEC-2AES Module set 12 4
