TX/MAM User Manual - document version: 2.4 – Page 46
9.9 Hardware preview
The TX/MAM HW-preview allows you to play out clips on a K2 Edge Channel and to preview in
TX/MAM.
To preview:
 In TX/MAM, select a clip and go to the Spotcheck tab.
 To load the clip, in the player panel, click the button.
 To switch to HW-preview, stop playout by clicking the button.
 Click the HW-button and open the dropdown menu, select a Channel.
 Click the button to start HW-preview.
Note how the HW-button turns orange when in HW-mode, as shown in the example below.
In HW-preview mode the shuttle slider, step, fast forward and go-to-end/beginning options are not
active. Also note that preview in TX/MAM and on the output are not in sync.
 To stop HW-preview, stop playout by clicking the button.

Click the HW-button and open the dropdown menu.
 Select Disable.
When a new clip is loaded, TX/MAM automatically switches to spotcheck-mode. Note how the HW-
button turns grey when in normal spotcheck-mode.
Configuration of HW-preview channels is described in the Commissioning Manual.
