Power Supply
Power Supply
See Table 10 for a list of power supply specifications. Specifications are
subject to change without prior notice.
Table 10. Power Supply Specifications
Parameter Value
Inputs
Voltage Range 100 V to 240 V, continuous range
Frequency 47 Hz to 63 Hz
Outputs
Voltage/Current +12.4 V @ 8 A and –12.4 V @ 1.5 A, common ground
(total not to exceed 100 W)
Load/Line Regulation ± 3% for loads from 100 mA to 5 A
+ 7%, – 3% for loads from 0 to 100 mA
Current Limit +12 V < 10 A under short circuit conditions
–12 V < 7 A under short circuit conditions
Status Range (healthy) +12 V + 8% – 4%; –12 V + 8% – 4%
Test Points Three: +12 V, –12 V, and ground
Power Factor Correction Complies with EN61000-3-2 Class D
