26 Gecko Frames — Instruction Manual
Section 1 — Gecko 8900 Series Frames
and offer more control and monitoring flexibility, both frame types are
offered in 8900TX, TF, and TFN models.
These models provide:
• 8900TX-V/TX-A – Vented cover for passive cooling and single 100 W
power supply for modules outputting up to 30 W power,
• 8900TF-V/TF-A – Fan front cover with a variable fan speed mode and
a single 100 W power supply, and
• 8900TFN-V/TFN-A – Fan front cover, 100W power supply, and
Ethernet capability for remote control and monitoring using a web-
based GUI (Graphical User Interface) with the 8900NET Network Inter-
face Module.
An 8900 Video frame can house 8900 Series video modules and Grass
Valley 8500 or 8800 analog distribution amplifiers (except the 8510R). The
frame can house from one to ten 8900 video modules depending upon
power requirements.
The 8900 Audio frame offers the same power, cooling, and control options
as the 8900 Video frame while providing a backplane with three-terminal
connectors for balanced audio inputs and outputs. Each audio module slot
provides 10 three-terminal connectors and four BNC connectors for func-
tions determined by the specific audio module installed.
Frame Options and Upgrades
Table 1 shows the Gecko 8900 Series frame models available. Table 2 pro-
vides the upgrade options available to extend the frame capabilities.
Table 1. Frame Models and Features
Model # Cover type/power max. Controller Active Comm. Ports
8900TX-V/TX-A Convection/30 Watts None None
8900TF-V/TF-A Fan Front Cover/100 Watts Frame Monitor Module Frame Alarm
8900TFN-V/TFN-A Fan Front Cover/100 Watts 8900NET Network Interface Module Frame Alarm, RS-232, Ethernet
Table 2. Frame Upgrade Options and Features for Both Video and Audio Frames
Model # Upgrade Cover type/power max. Controller Active Comm. Ports
8900FAN 8900TX to 8900TF Fan/100 Watts Frame Monitor Module Frame Alarm
8900FN 8900TX to 8900TFN Fan/100 Watts 8900NET Network Interface Module Frame Alarm, RS-232, Ethernet
8900NET 8900TF to 8900TFN Fan/100 Watts 8900NET Network Interface Module Frame Alarm, RS-232, Ethernet
