Gecko Frames — Instruction Manual 47
Power Connections
Line Cord Retainer
To help prevent accidental loss of power, the AC line cord is held in place
by a retainer clip (
Figure 18 ).
Figure 18. Cable Retainer Clip
To properly install the line cord, follow these steps:
1. Ensure that the retainer clip is inserted properly into the holes of the
screw caps.
2. Rotate the retainer clip sideways, and plug the power cord into the
receptacle.
3. Rotate the retainer clip back onto the plug body to hold the power cord
in place.
Retention Clip
0636 -08
