Configuring Editing Environments
26 EDIUS - Hardware Setting Guide
[Stereoscopic Settings] (STORM 3G ELITE/STORM 3G)
0
The settings of an output device used for printing to tape.
[Stereoscopic Mode] Select a stereoscopic processing format when outputting the video of the L
side and the R side in the project created in the stereoscopic edit mode.
When [L/R Dual Stream] is selected, output the video of the L side and the R
side with 2 streams maintained.
When [L Only]/[R Only] is selected, export the video of either the L side or the
R side.
When [Side by Side]/[Top and Bottom]/[Line Interleave]/[Blend]/[Anaglyph]/
[Difference]/[Split Grid] is selected, export the composite video of the L side
and the R side.
[Follow stereoscopic preview
mode] Output the video in the same format as the preview window display in the
stereoscopic edit mode.
[Swap L/R] Check this option to display video with the L side (for left eye) and R side (for
right eye) swapped.
[SDI Output Setting] Set how to output 2 streams from the SDI OUT terminal when [L/R Dual
Stream] is selected in STORM 3G ELITE.
[OUT-A]:[L], [OUT-B]:[R]
Output the L side video from the SDI OUT (A) terminal, and output the R
side video from the SDI OUT (B) terminal.
[OUT-A]:[3G], [OUT-B]:[3G]
Output the L+R (3G-SDI) video from the SDI OUT (A) terminal, and output
the L+R (3G-SDI) video from the SDI OUT (B) terminal.
[OUT-A]:[3G], [OUT-B]:[L]
Output the L+R (3G-SDI) video from the SDI OUT (A) terminal, and output
the L side video from the SDI OUT (B) terminal.
[OUT-A]:[3G], [OUT-B]:[L(SD)]
Output the L+R (3G-SDI) video from the SDI OUT (A) terminal, and down-
convert the L side video from the SDI OUT (B) terminal to SD and output the
video.
[Default] Restore the default settings.
