Chapter 2 - Basic Operations
40
202 audio headroom
Balanced audio headroom
(Reference level)
LCD display
202 audio headroom
>>>
sub-menu
in headroom ch 1
16dB Specifies the input headroom of CH 1.
16 dB Sets to 16dB.
18 dB Sets to 18dB. (Factory default for PAL/SECAM)
20 dB Sets to 20dB. (Factory default for NTSC)
in headroom ch 2
16dB Specifies the input headroom of CH 2.
16 dB Sets to 16dB.
18 dB Sets to 18dB. (Factory default for PAL/SECAM)
20 dB Sets to 20dB. (Factory default for NTSC)
out headroom ch 1
16dB Specifies the output headroom of CH 1.
16 dB Sets to 16dB.
18 dB Sets to 18dB. (Factory default for PAL/SECAM)
20 dB Sets to 20dB. (Factory default for NTSC)
out headroom ch 2
16dB Specifies the output headroom of CH 2.
16 dB Sets to 16dB.
18 dB Sets to 18dB. (Factory default for PAL/SECAM)
20 dB Sets to 20dB. (Factory default for NTSC)
Specifies the input/output headroom of the
Balanced audio (XLR).
Press the Select dial to display the sub-menu.
In the sub-menu, turn the Select dial to choose the sub-menu item.
