8964DEC/-FS — Instruction Manual 67
Configuration Summary
Table 8 provides a complete summary of the 8964DEC processing functions
and a comparison of the functionality available with each control type
along with the ranges and default values for each parameter. The table is
organized to provide a breakdown of the video path processing adjust-
ments by specific grouping of line type in the video signal.
Table 8. Summary of 8964DEC Configuration Functions By Line Type
Processing
Function
Type
Default
Range/Choices
Resolution
Web Page/
Function Name
Rotary
Switch
Bank/Setting
Newton
Control
Panel
Notes/
Conditions
All Lines, Channels 1–4. Composite In Video Path Processing (before decoding).
Input signal status N/A Present/Not Present
Status/
CV Input 1-4 status
N/A SigStt1-4
Read-only signal
input reporting
Reference input status N/A
Present/
Warn- Not Locked
Status/
Ref Input status
N/A RefStt
AGC (Auto Gain Control) Off On/Off
Video Composite In/
Enable AGC checkbox
1:3 N/A On enables AGC
ACC (Auto Chroma Control) Off On/Off
Video Composite In/
Enable ACC checkbox
2:9 N/A On enable ACC
Input Video Gain 100%
72.5–200%
(0.5% steps)
Video Composite In/
Input Video Gain (%)
1:4 vciGain1-4 AGC off.
Input Chroma Gain 100%
50–200%
(0.6% steps)
Video Composite In/
Input Chroma Gain (%)
1:5 vciChGn1-4 ACC off.
Detail Enhancer Disable
Disable, Low,
Medium or High
Picture Enhancer/
Select Disable, Low, Medium
or High radio button
3:B (Disable
or Low)
3:C (Medium
or high)
N/A
8964DEC and
8964DEC-FS
Active Picture Lines, Video Path Processing, Channels 1–4. All settings Global (affects all active picture lines).
Saturation/Chroma Gain 100%
50–200%
(0.6% steps) 1
Video Proc/
Saturation/Chroma Gain (%)
1:8 ChrGain1-4
Active only when
Video Proc is
enabled.
Hue/Chroma Phase 0
± 180 degrees
(1.4 degree steps) 1
Video Proc/
Hue/Chroma Phase (deg)
1:9 ChrmPhs1-4
Brightness/Y Offset 0
± 400 mV
(3 mV steps)
1
Video Proc/
Brightness/Y Offset (mV)
1:7 YOffset1-4
Contrast/Y Gain 100%
50–200%
(0.6% steps)
1
Video Proc/
Contrast/Y Gain (%)
1:6 YGain1-4
Remove setup from active video Yes Yes/No
Video Composite In/
Remove setup from active video
checkbox
1:2 N/A 525 only.
TSG (Test Signal Generator)
(100% Color Bars)
Off On/Off
Video Proc/
Color Bars 100% checkbox
1:D
(enable mode)
1:E
(choose type)
TstSig1-4
Test signals are
not adjustable.
TSG (Test Signal Generator)
(Pathological)
Off On/Off
Video Proc/
Pathological Test checkbox
OSD (On Screen Display) Off On/Off
OSD Control/
On Screen Display
1:1 N/A
Jumper JP3 must
be enabled on
module.
