36 8964DEC/-FS — Instruction Manual
Configuration
8964DEC Links and Web Pages
The 8900 GUI provides the following links and web pages for the 8964DEC
module (
Figure 12 ):
• Status – reports input and reference signal status and module informa-
tion (
page 37 ),
• I/O Config – shows a graphic representation of inputs and outputs to
the module and allows naming of each input (
page 40 ),
• Functional View – shows a block diagram of the module with links to
each configuration web page (
page 41 ),
• Module Configuration web pages for setting up the module ( page 42 ),
• E-MEM – provides Learn and Recall functions for up to 5 E-MEM reg-
isters along with
Save to and Load from file operations ( page 52 ),
• OSD Control – provides controls to enable or disable the OSD for each
channel (
page 56 ), and
• Slot Config – provides a Locate Module function, Slot Identification,
and Slot Memory in addition to links to the Frame Reporting, LED
Reporting and SNMP Reporting web pages (
page 57 ).
Figure 12. 8964DEC Web Page Links
