28

8937/8937D — Instruction Manual

Configuration

Status Web Page

The Status web page (

Figure 14 on page 29

for 8937 and

Figure 15 on

page 29

Use
this
link

for the 8937D) shows the signal status of the input signal(s) and

communication with the frame bus. Color coding of the display indicates
the signal status. In general, graphics and text colors used for status indica-
tion are the following:

Green = Pass – signal or reference present, no problems detected.

Red = Fault – fault condition.

Yellow = Warning – signal is absent, has errors, or is mis-configured.

Gray = Not monitored.

Note

Always refresh the page first with the Refresh button at the top of the page
(shown at left) to update the current status of the web page.

On the Status web page for the 8937D module, signal status of both input
signals is represented by a single input signal arrow. Signal reporting to this
status indicator can be disabled at the module level for either or both DA 1
and DA 2 on the Standard Selection web page. When input signal status
reporting is enabled for both DAs, if the status of either input signal
changes, it will be reflected in the color status of the arrow and the Status
LED on the module web pages. To determine which signal has been
affected, refer to the Standards Selection web page or the on-board front
edge LEDs.

The collective input state for the 8937D input signal arrow is summarized
in

Table 3

. In the table under DA 1 and DA 2,

Not Monitored

indicates the

Report Loss of Signal

control for that DA has been disabled on the Standard

Selection web page. For SNMP reporting, the reporting is separate for each
DA. Refer to

SNMP Trap Reports on page 37

.

Information about the module, such as part number, serial number, hard-
ware revision, software version, and Asset Tag number are given in a

Prop-

erties

section at the bottom of the Status page display.

Table 5. 8937D Collective Status State for Input Signal

DA 1

Input Status

DA 2

input Status

Collective

Input Status

Input Signal Arrow

Color

Not Monitored

Not Monitored

Not Monitored

Gray

1

1

When signal loss reporting for both DAs is disabled, the Status LED on each web page will continue to monitor module

status but will not respond to signal status changes.

Signal Not Present

N/A

Signal Not Present

Yellow

N/A

Signal Not Present

Signal Not Present

Yellow

Signal Present

Not Monitored

Signal Present

Green

Not Monitored

Signal Present

Signal Present

Green

Signal Present

Signal Present

Signal Present

Green
