Embedded Inputs
Number:
Four AES Streams (from video input)
Eight channels from any two of four groups
Selectable to any of four groups
Type:
SMPTE 274M Compliant
Selectable to any of four groups
Channels:
Eight
Bit Depth:
20 or 24 Bit
AES/EBU Digital Outputs
Number:
Four (total of eight channels)
Type:
AES3id
Connectorization:
Coaxial, 75 Ω BNC
Bit Depth:
20 or 24 Bit
Sample Rate:
48kHz
Synchronous to Video output
Reference Level:
-18 or -20 dBFS (Selectable)
Embedded Output
Number:
Four or two, depending on configuration
Group Assign:
Cascade, or Replace any of two of four groups
Channels:
Eight
Bit Depth:
24 Bit
General Specifications
Power Consumption:
< 10 Watts
Temperature Range:
0 to 40 degrees C ambient (all specs met)
Relative Humidity:
0 to 95% noncondensing
Altitude:
0 to 10,000 ft
Due to ongoing product development, all specifications subject to change.
