Model 7900 HD Up/Down/Cross Converter
When Manual is selected in the Mode menu, you may set the output format mode of the
upconverted HD output with the following controls:
• Width – sets the aspect ratio width.
•
Height – sets the aspect ratio height.
•
Hor Position – sets the horizontal position of the output.
•
Ver Position – sets the vertical position of the output.
Use the Default button in each control to return to the default value.
Use the Config menu below to enable the following controls:
•
Noise Reduce – adjusts the amount of noise reduction on the output signal
from Off, Low, Medium, or High. The typical setting for this parameter is
Off or Low.
•
Detail – adjusts the amount of picture detail enhancement on the output
from Low, Medium, or High. The typical setting for this parameter is Off
or Low.
•
3:2 Detect – turns the control to detect video that has been converted from
film, On or Off. Use this only for film applications. The typical setting for
this parameter is Off.
