7900-45
SPECIFICATIONS
7900 HD Up/Down/Cross Converter
Serial Digital Input:
Number: One
Signal Type: HD Serial Digital 1.485 Gb/s
SMPTE 274M, 292M or 296M
or SD Serial Digital 270 Mb/s
SMPTE 259M
(both 525 and 625 SD standards)
Impedance: 75 Ω, BNC
Return Loss: >15 dB
Maximum Cable
Length:
270 Mb/s
300 meters (Belden 1694A or equivalent)
1.485 Gb/s 100 meters (Belden 1694A or equivalent)
HD Standards Supported:
1080i (SMPTE 274M -4,5,6) 50, 59.94, 60 Hz
720p (SMPTE 296M -1,2,3) 50, 59.94, 60Hz
1080p (SMPTE 274M -9,10,11) 23.98, 24, 25 Hz
1080sF (RP211 -14,15,16) 23.98, 24, 25 Hz
Serial Digital Output
Number: Two, Three, or Four selectable
Type: SMPTE 274M or 296M when HD
SMPTE 259M
(525 or 625) when SD
Processing 12 and 16 bit
Impedance: 75 Ω, BNC
Return Loss: >15 dB
Output DC: None (AC coupled)
Reference Input
Number: One external (module’s BNC)
One internal (frame master ref BNC)
Signal Type: PAL or NTSC composite video
or HD Tri-Level Sync
SMPTE 274M or 296M
Return Loss: >40 dB (applies to external ref input)
Model 7900 HD Up/Down/Cross Converter
