SPECIFICATIONS
63
125 hexagon bolt
126 spring washer
127 pin
128 hexagon screw
129 spring washer
137 PVC hose
138 hose clip
143 specially compounded lubricant
144 Sticker
145 T with hose nipple
146 deseration pipe with hose nipple
147 air breather cap
148 drain plug
152 grease
153 cylinder screw
154 cleansing sponge
161 strip
162 hexagon screw
163 spring washer
186 insert stainless steel Choice of one of these inserts
187 insert PVC
189 insert PP (polypropylene)
190 insert PVDF
197 flange bracket
198 flange steel Drawing shows the construction for the
steel and Stainless steel insert. For the
PVC, PP, and PVDF install with the
chamfered side to the hose.
424 hexagon screw
430 hexagon screw
431 spring washer
432 hexagon screw
433 spring washer
POS. no. Description Remarks
