72 Pitch and Speed
Frame Number and Pitch Types
The frame number sent with each RTD frame also represents the pitch type (for manual
mode). The pitch types for each frame number are shown below. Standard RTD Port
configuration: 1,200 Baud Rate, 8 Data Bits, and No Parity for the Jugs or Stalker Sport gun
type. Use a Baud Rate of 9600 for the Stalker Pro gun.
Frame # Pitch Type
1 Curve Ball
2 Slider
3 Sinker
4 Change Up
5 Knuckle Ball
6 Fast Ball
7 Split Finger
8 Screw Ball
9 Breaking Ball
10 (Blank)
11 Other
12 User 1
13 Off Speed
14 User 2
15 User 3
16 Fork Ball
17 User 4
18 Palm Ball
19 Home Pitch Count
20 Guest Pitch Count
