28 Basic Operations
Single Controller Systems Channel Setting
Typically all single controller systems will use the default setting BCAST = 1, CHAN = 1. All
radio receivers must be set with a switch setting of 1 with the Broadcast 1 (BCAST 1) jumper
set.
If you suspect interference from a nearby Daktronics system, press <CLEAR> at the
“RADIO SETTINGS” prompt to change the channel number.
Typically all multiple controller systems will use channel 1 for the first controller. All other
controllers will use sequential channel settings (2-8). The following table describes broadcast
channel and channel settings.
LCD Display Action
The LCD will toggle these
screens.
bcast group 1
radio chan 01
Enter to accept
clear to modify
The bottom line shows
default settings.
RADIO SETTINGS
BCAST Y CHAN XX
The LCD shows the current radio settings along
with a prompt to accept or modify these values.
If the radio settings are correct press <ENTER>
If these values are incorrect press <CLEAR>
If <CLEAR> is pressed to modify the radio settings
the LCD at the left is shown, allowing edit of the
channel or broadcast group setting.
Edit the broadcast setting. Use the number keys to
enter the desired broadcast group and press
<ENTER> to accept.
Broadcast Group Setting
1 Use this setting for all single controller
systems the asterisk will move to the
channel setting. Use the number keys to
edit this value and press <ENTER> to
accept. Edit the channel number to the
desired value and press <ENTER> to
accept.
Channel Setting
1-8 Channels that may be used with broadcast
channel 1. The channel switch on the
receiver must match this value and only the
Broadcast 1 (BCAST1) jumper must be
installed.
