Model 765 RVC Hydraulic Power Supply
92-0306 : Rev. 140715
Volume Control
Pendant rheostat with the integrated Electric Displacement Control (EDC)
Pump.
Pressure
0 psi (0 kPa) to 1800 psi (12410 kPa) forward.
0 psi (0 kPa) to 1400 psi (9653 kPa) reverse.
Pilot-operated bypass (pressure limiting) valves (2) are included in the for-
ward and reverse flow lines.
A closed loop system has been designed in for minimum heat generation.
A full flow return “loop” 10-micron filter is in the system to prevent contamina-
tion from circulating through the pump.
The Filter Assembly incorporates a visual Filter Clogging Indicator.
The tank suction line contains a 10-micron filer.
Cooling
A heat exchanger is built into the reservoir return line.
Hydraulic Reservoir
The reservoir has a capacity of 18 gal (68 Lt.).
The reservoir includes a level and a temperature gauge.
Hydraulic Fluid Compatibility
The system requires a petroleum-based hydraulic fluid.
Ethylene glycol/water based fluids may also be used. However, it is recom-
mended that you contact the factory regarding specifics of operation on those
types of fluids.
