15
Remote control unit
• For details, refer to the separate (supplied) RC-8000 operating instructions.
The USB terminal is a terminal that will be used in the future to update the microprocessor program, etc.
q
Transmitter
w
Touch panel
e
CHANNEL up/down buttons
r
MUTE button
t
USB terminal
y
Jog stick (PUSH ENTER)
u
VOL. (volume) up/down buttons
i
LIGHT (back light) button
o
Battery charging contacts
!0
RF frequency selector switch
!1
Reset button
!2
Battery cover
