NOZZLE ASSEMBLY PARTS LIST

REF#

PART#

DESCRIPTION

QUANTITY

1*

16-920-01

Screw

2

2*

16-920-02

Upper Clamp

1

3*

16-920-03

O-Ring

1

4*

16-920-04

Body with Lower Clamp

1

5*

16-920-05

Diaphragm Teflon

(Optional)

1

6*

16-920-06

Diaphragm EPDM Rubber

(Standard)

1

*

16-920-07

Diaphragm Viton

(Optional)

1

7*

16-798

Chemsaver End Cap

1

8

16-800

Gasket Viton

1

9

16-921

Cap

1

10

16-805

Raindrop Tip

1

/

4

RA8

1

*

16-920

Body

1

When the 16-920-05 Teflon Diaphragm is used, it is placed in the assembly in front of the
16-920-06 EPDM Rubber Diaphragm. Nozzles are located 20" (51 cm) apart on the right, left,
and center tubes . There are predrilled holes in all tubes. The Nozzle should be at a 45° angle
to the ground for proper application.

For all 18' Booms:

The eleven 16-920 bodies are installed on the boom sections. The

eleven 16-800 viton gasket, 16-805 Raindrop tip and 16-921 cap are in the small parts bag.

For all 15' Booms:

The nine 16-920 bodies are installed on the boom sections. The nine

16-800 viton gasket, 16-805 Raindrop tip and 16-921 cap are in the small parts bag.

(for 10-301 Booms)

BOOM WIRING PARTS LIST

PART#

DESCRIPTION

QUANTITY

8853

Slide on Connectors

2

8963

Heat Shrink

1

/

4

"

2

15-472

Switch Boot

2

11-158

Linear Actuator with 4" stroke

2

16-755

Switch

2

16-810

Wiring Harness

1

22-075

Nylon Tie

12

33-272

Fuse 20 amp

1

Use Dielectric Grease On All Electrical Connections

WIRING INSTRUCTIONS

1.

Mount the two switches on the control on the right hand side of the machine. Connect the wiring

harness (16-810) to the switches (16-755) and fuse block as shown in the boom wiring diagram. Put 20
amp fuse (33-272) into the fuse block as shown.

2.

Run the wire harness back to the boom along the main frame keeping it away from hot or moving

parts. Use the nylon tie (22-075) to hold it in place.

3.

Connect the wiring harness to the linear actuator (11-158) as shown. Use a nylon tie on each

actuator to hold the wires to the fixed end of actuators.
