11
Diagrams
WIRING PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1† 10-202 Speedometer 1
8859 Ring Terminal 3 /
16
2
8962 Heat Shrink 2
2 8935 Buss Bar (-) 1
3 13-288 Ignition Switch (Kohler 25 099 04) 1
76-310 Key Set 1
4 34-146 Panel Mounted Circuit Breaker 1
34-145 Circuit Breaker Boot 1
5 8935 Buss Bar(+) 1
6§ Speedometer To (+) Buss Bar
7§ (-) Buss Bar to Hour / Voltmeter
8 42-064 Hour / Voltmeter Combo 1
9 10-182 Hot Wire Hour / Voltmeter 1
10 50-359 Oil Warning Light 1
8849-2 Black Wire 1
8860 String Connector 1
8859 Ring Terminal 3 /
16
1
8853 Slide On Connector 1
8962 Heat Shrink 3 /
16
3
11 Oil Sender (Part Of Engine)
12 Ignition Module (Part Of Engine)
13 Fuel Shut-Off Solenoid (Part Of Engine)
14 Rectifier (Part Of Engine)
15 Starter (Part Of Engine)
16 10-167 Red Battery Cable 1
17 22-073 Battery (Optional) 1
18 76-327 Ground Battery Cable 1
19 10-204 Fuse Block Ground Wire 1
20 33-271 Fuse Block 1
21 10-203 Fuse Block Hot Wire 1
22 Wire With Fuse (Part Of Engine)
Fuse AGC 30
23§ (-) Buss Bar to Ignition Switch
24 77-207 Buzzer 1
8845-3.5 White Wire 1
8860 String Connector 1
8859 Ring Terminal 3 /
16
1
8853 Slide On Connector 1
8962 Heat Shrink 3
25§ Wire Toggle Switch To (+) Buss Bar
26 33-480 Pressure Switch 1
27 15-314 Toggle Switch 1
15-472 Switch Boot 1
28 16-966 Hypro Pump With Electric Clutch 1
29† 10-183 Wire Speedometer Ground 1
30† 16-883 Magnetic Sensor 1
31† 10-209 Speedometer Wire Harness 1
32 14-272 Seat Switch 1
10-262 Wire Harness (Includes all wire colors with *) 1
§ 10-224 Console Wire Harness 1
† 10-108 Speedometer Kit (optional)
