13
Diagrams
HYDRAULIC DIAGRAM PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 10-143 Hydraulic Hose 2
2 10-135 Hydraulic Cylinder 1
3 10-141 Hydraulic Hose 1
4 34-103 Orbitrol Motor 1
5 10-144 Hydraulic Hose 1
6 10-142 Hydraulic Hose 1
7 18-190 Tee 1
8 34-105 Oil Cooler 1
9 10-145 Hydraulic Hose 1
10 10-116 Wheel Motor 2
11 10-123 Hydraulic Hose 4
12 8832-12 Hose 3 /
4
ID 1
18-222 Hose Clamp 2
13 23-006 Oil Filter 1
23-031 Replacement Filter
14 8832-14 Hose 3 /
4
ID 1
18-222 Hose Clamp 2
15 10-196 Hydraulic Hose 1
16 48-135 Oil Tank 1
17 10-140 Hydraulic Hose 2
18 10-117 Hydrostatic Pump 1
FITTING TORQUE CHARTS
Over tightened fittings will result in crushing the cone which will create a leak.
Charts Developed by Parker Henniphin
in. lbs. ft. lbs. in. lbs. ft. lbs.
2 5/16 - 24 35 ± 5 3 ± .5 90 ± 5 7.5 ± .5
3 3/8 - 24 60 ± 5 5 ± .5 170 ± 10 14 ± 1
4 7/16 - 20 135 ± 10 11 ± 1 220 ± 15 18 ± 1
5 1/2 - 20 180 ± 10 15 ± 1 260 ± 15 22 ± 1
6 9/16 - 18 220 ± 10 18 ± 1 320 ± 20 27 ± 2
8 3/4 - 16 550 ± 20 46 ± 2 570 ± 25 48 ± 2
10 7/8 - 14 900 ± 50 75 ± 5 1060 ± 50 90 ± 5
12 1 1/16 - 12 1020 ± 50 85 ± 5 1300 ± 50 110 ± 5
14 1 3/16 - 12 1550 ± 75 130 ± 6 1750 ± 75 145 ± 6
16 1 5/16 - 12 1600 ± 75 135 ± 6 1920 ± 75 160 ± 6
20 1 5/8 - 12 2700 ± 150 225 ± 12 2700 ± 150 225 ± 12
24 1 7/8 - 12 3000 ± 150 250 ± 12 3000 ± 150 250 ± 12
32 2 1/2 - 12 3900 ± 200 325 ± 15 3900 ± 200 325 ± 15
SAE Straight Thread O-ring Plugs
(Steel)
Fitting
Size
SAE Port
Thread
Hollow Hex Head Plug
(HP5ON) Assembly
Torque
Hex Head Plug (P5ON)
Assembly Torque in. lbs. ft. lbs.
4 7/16 - 20 190 ± 10(1) 16 ± 1.0
6 9/16 - 18 420 ± 15 35 ± 1.0
8 3/4 - 16 720 ± 25 60 ± 2.0
10 7/8 - 14 1260 ± 50 105 ± 5.0
12 1 1/16 - 12 1680 ± 75 140 ± 6.0
16 1 5/16 - 12 2520 ± 100 210 ± 8.0
20 1 5/8 - 12 3100 ± 150 260 ± 12.0
24 1 7/8 - 12 3800 ± 150 315 ± 12.0
Seal-Lok Straight and Adjustable Fitting
(Steel)
Assembly Torque (2)
Fitting
Size
SAE Port
Thread
Size
