Seaward DO5000 Interface User Manual
Page 40
- 40 -
APPENDIX II
RS-232 Pin Connections
1
DCD
Data Carrier Detect
(not connected)
2
RXD
Received Data (input)
3
TXD
Transmitted
Data
(output)
4
DTR
Data Terminal Ready
(not connected)
5
GND
Signal
Ground
6
DSR
Data Set Ready
(not connected)
7
RTS
Request To Send
(output)
8
CTS
Clear To Send
(input)
9 RI
Ring
Indicator
(not
connected)
APPENDIX III
IEEE-488 Pin Connections
1
DIO1
Data Input/Output 1
2
DIO2
Data Input/Output 2
3
DIO3
Data Input/Output 3
4
DIO4
Data Input/Output 4
5
EOI
End Or Identify
6
DAV
Data Valid
7
NRFD
Not Ready For Data
8
NDAC
Not Data Accepted
9
IFC
Interface Clear
10
SRQ
Service
Request
11
ATN
Attention
12
CABLE
SHIELD
13
DIO5
Data Input/Output 5
14
DIO6
Data Input/Output 6
15
DIO7
Data Input/Output 7
16
DIO8
Data Input/Output 8
17
REN
Remote
Enable
18
DAV
ground
19
NRFD
ground
20
NDAC
ground
21
IFC
ground
22
SRQ
ground
23
ATN
ground
24
LOGIC
ground
