5. System setting and operation
How to set picture-in-and-out effect
VSP 737 User Manual 75
How to Set Picture-in-and-out Effect
Firstly assure the device is powered on. Details are in: How to Confirm the
Device is in Normal Operation.
1. Select the layer to be edited, tap , key lights on, the current layer
is selected; Preview picture‘s red frame shows current system‘s default
shifting position and size;
2. Rotate the knob to set on shifting picture, items below include:
POS X MOVE SETUP; POS Y MOVE SETUP; WIDTH MOVE SETUP;
HEIGHT MOVE SETUP;
At the time, key blinks always;
3. When items above are set, tap , key lights on without blinking,
LCD screen shows:
4. Tap , choose switching keys to realize
picture-in-and-out effect;
5. Tap , key lights off, MOVE SETUP functions off, LCD screen
shows:
Note
Apply and together to realize MOVE SETUP, after
tapping , assure key lights on without blinking, or
else key is not editable.
END MOVE STEUP
CLEAR MOVE SETUP
