94
Removing and Installing Parts
www
.dell.com | support.dell.com
Installing a Hard Drive
1 Unpack the replacement hard drive, and prepare it for installation.
2 Check the documentation for the drive to verify that the drive is configured for your
computer.
3 If your replacement hard drive does not have the hard drive bracket attached, remove the
bracket from the old hard drive by unsnapping it from the drive.
4 Snap the hard drive bracket onto the replacement hard drive.
5 Install the hard drive into the computer by sliding the drive into place until you feel it click
into place.
6 Connect the power and hard drive cables to the hard drive.
7 Check all connectors to be certain that they are properly cabled and firmly seated.
8 Close the computer cover.
hard drive
hard drive bracket
hard drive cable
power cable
