Removing and Installing Parts
89
Drive Panels
CAUTION:
Before you begin any of the procedures in this section, follow the safety instructions in the
Product Information Guide.
CAUTION:
To guard against electrical shock, always unplug your computer from the electrical outlet
before removing the cover.
Removing the Drive Panel
1 Follow the procedures in "Before You Begin" on page 63.
2 Grasping the lever on the sliding plate, pull the sliding plate to the right and hold in place.
NOTE:
The sliding plate secures and releases the drive panel and helps to secure the drives.
drive panel
sliding plate
sliding plate lever
