86
Removing and Installing Parts
www
.dell.com | support.dell.com
15 If you installed an add-in network adapter and want to disable the integrated network
adapter:
a Enter system setup select Integrated NIC Controller, and then change the setting
to Off.
b Connect the network cable to the add-in network adapter’s connectors. Do not connect
the network cable to the integrated connector on the back panel.
16 Install any drivers required for the card as described in the card documentation.
Removing a PCI Express Card
1 Follow the procedures in "Before You Begin" on page 63.
2 Remove the computer cover (see page 68).
3 If present on your computer, rotate the lever on the chassis wall upward.
card retention
door
release tabs (2)
filler bracket
alignment guide
alignment bar
*lever on chassis wall
*may not be present on all computers
