102
Removing and Installing Parts
www
.dell.com | support.dell.com
7 Connect the FlexBay USB cable to the back of the Media Card Reader and to the Media Card
Reader connector on the system board (see page 71).
8 Insert the Media Card Reader into the bay and slide the drive in to seat it in the computer.
9 Route the USB cable through the cable routing clip.
10 Replace the computer cover (see page 107).
CD/DVD Drive
CAUTION:
Before you begin any of the procedures in this section, follow the safety instructions in the
Product Information Guide.
CAUTION:
To guard against electrical shock, always unplug your computer from the electrical outlet
before opening the cover.
USB cable
*Media Card Reader
*
Not present on all computers.
